NOW AVAILABLE
JOYCHARGER Automatic Outdoor Charger
Type of battery: Li-Polymer/NiCd/NiMH
Input DC: 11V to 15V Max approx. 3A
Number of Lipo cells: 1-3 Li-Poly Cells
Number of NiCd/NiMH cells: 1-8 NiCd/NiMH Cells
Charge Voltage Li-Poly: 4.2V,8.4V,12.6V
Charge VoltageNiCd/NiMH: Automatic Charge Current 0.3A,0.6A,1.2A,2A
Weight : 80g
Dimensions : 92(L) x 55(w) x 12(H)mm
Constant voltage or constant current (CVCC) configuration optimally charges Lithium-Polymer battery cells.
High frequency switch mode topology is adopted to achieve high efficiency, small size, cool temperature and lightweight.
Reverse polarity protection both at input and output is provided.
Low-voltage detection circuit enables a wake up charge source of 30mA automatically to precondition a deeply discharged pack when the cell voltage drops below a preset limit.
Two LEDs in red and green are used to indicate information of charging modes and alarms.
